1、美观的外形,流线型的轮廓使其显得异常出众;
2、高质量的钢材确保车辆拥有出色的稳定性和强度;
3、本产品主要用于货物的装卸,动力提升,高效轻便;
4、配用集成一体化的液压动力单元;
5、精巧车身设计,操作灵活简便;
6、工作电压为12V,智能充电机,自动调节充电电流及充足后自动停机;
7、整体设计具有噪音低、压力高、外形美观、结构小巧、操作简单优点。
名称(Name) |
半电动堆高车(12V) |
|||||||
型号 (Model No.) |
单位 |
EFA10-16 |
EFA10-25 |
EFA10-30 |
EFA10-35 |
EFA15-25 |
EFA20-16 |
|
载重 (Capacity) |
Kg |
1000 |
1000 |
1000 |
800 |
1500 |
2000 |
|
最大起升高度 (Max lifting height) |
H2(mm) |
1600 |
2500 |
3000 |
3500 |
2500 |
1600 |
|
载荷中心 (Load center) |
C(mm) |
500 |
500 |
500 |
500 |
500 |
500 |
|
货叉尺寸 (Fork size) |
mm |
1150X160 |
1150X160 |
1150X185 |
||||
货叉外宽 (Fork Outer distance) |
S1(mm) |
680 |
680 |
680 |
680 |
680 |
705 |
|
全长 (Overall Length) |
L(mm) |
1800 |
1800 |
1800 |
1800 |
1800 |
1800 |
|
全宽 (Overall Width) |
S(mm) |
775 |
775 |
775 |
775 |
775 |
775 |
|
门架闭合时高度 (Height--Mast Lowered) |
H1(mm) |
2075 |
1825 |
2075 |
2325 |
1825 |
2075 |
|
货叉起升时最大高度(含货叉架) (Maximum height when fork is lifting ) |
H3(mm) |
2075 |
3033 |
3530 |
3940 |
3033 |
2075 |
|
货叉最低高度 (The minimum fork height) |
h1(mm) |
85 |
85 |
85 |
85 |
85 |
85 |
|
转弯半径 (Turning radius) |
WQ(mm) |
1365 |
1365 |
1365 |
1365 |
1365 |
1365 |
|
最小堆垛通道宽度(1000*1000托盘) (Min. stacking aisle) |
mm |
2140 |
||||||
前轮至叉端距 (The front wheels to the fork end distance) |
mm |
428 |
428 |
428 |
428 |
428 |
428 |
|
总重 (Total weight) |
Kg |
341 |
383 |
402 |
421 |
502 |
421 |
|
起升马达 (Lifting motor) |
Kw |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
|
电池容量 (Battery capacity) |
V/Ah |
12/120 |
12/120 |
12/120 |
12/120 |
12/120 |
12/120 |
|
充电电压 (The charging voltage)(V) |
V |
~220 |
~220 |
~220 |
~220 |
~220 |
~220 |
|
